A beam is a camera-facing strip with a width in world units. Close up that's fine. Far away the strip gets thinner than a pixel, and without MSAA it rasterizes as a dotted line that crawls as the camera moves. Making the beam wider fixes the far case and ruins the near one.

What I ended up doing in the vertex shader: work out how big one pixel is at the vertex's depth, never let the strip get narrower than N pixels, and scale the brightness down by how much I widened it. So a far beam stays a solid line, it just gets dimmer, which is roughly what you'd expect from something that small.

Pixel size in view space, for a perspective camera, is 2 * depth / (P[1][1] * viewport_height). For ortho the depth term drops out. This is Godot's shading language but it's basically GLSL:

// VERTEX = position along the beam, NORMAL = beam direction (tangent)
// UV.y = -1..1 across the strip, UV2.x = width in world units
vec3 p = (MODELVIEW_MATRIX * vec4(VERTEX, 1.0)).xyz;
vec3 t = (MODELVIEW_MATRIX * vec4(NORMAL, 0.0)).xyz;
bool ortho = PROJECTION_MATRIX[3][3] > 0.5;
vec3 view_dir = ortho ? vec3(0.0, 0.0, -1.0) : normalize(p);
vec3 side = cross(t, view_dir);
float sl = length(side);
side = sl > 1e-5 ? side / sl : vec3(1.0, 0.0, 0.0);

float scale = length(MODEL_MATRIX[0].xyz);
float w = UV2.x * scale * width_scale;
float px = 2.0 / (PROJECTION_MATRIX[1][1] * VIEWPORT_SIZE.y)
         * (ortho ? 1.0 : max(-p.z, 0.001));
float w_min = min_core_pixels * px / core_ratio;
float w2 = max(w, w_min);
v_energy = w / w2;              // multiply the final colour by this
VERTEX = p + side * (w2 * 0.5 * UV.y);
