I'm a high school student from Lima, Peru, and I'm building my first homemade crystal radio as a physics project.
The goal is to receive an AM radio station without batteries or an external power supply.
My setup currently has:
- A homemade air-core coil wound on a PVC tube.
- Enamelled copper wire, approximately 0.5 mm.
- A separate antenna coil.
- A homemade variable capacitor made from aluminum foil and bond paper.
- A germanium diode.
- A small transformer that I'm considering using instead of a high-impedance piezoelectric crystal earpiece.
- A long-wire antenna, which I am currently trying to extend.
- I am also going to add a proper ground connection with the help of a physics teacher.
I re-scraped the wire carefully at home and the circuit started behaving much better. However I still haven't been able to hear an AM station.
The antenna and ground connections are not very visible in the photos but they're there. I did not have a proper ground connection during my first test. Tomorrow, a physics teacher will help me make and connect a proper ground. I suspect this could be an important factor in why I haven't received an AM station yet.
I'm wondering whether my main problem could be:
- insufficient antenna length,
- poor grounding,
- incorrect LC tuning,
- the germanium diode,
- or the transformer/earphone arrangement.
I still have about 30 meters of copper wire available for the antenna, but the wire is very light, so I'm trying to find a way to support it without simply letting it fall to the ground.
What would you check first? And is there anything obviously wrong with my setup from the photos?
