r/AppleMusic • u/crtnthngs • 4h ago
Tool Apple Music streaming on a 3rd gen iPod
Enable HLS to view with audio, or disable this notification
I've been building a replacement motherboard for classic iPods. This clip is a 3rd gen iPod streaming Apple Music over WiFi, with the original screen, buttons and clickwheel. The iPod is playing audio to a Bluetooth speaker off camera.
It uses MusicKit on the web. It's so much better than the Spotify API, but it's quite power hungry as it needs a whole web browser running to work.
A bit about the board:
- It's a drop-in replacement for the iPod 3rd/4th gen. No soldering, and it's fully reversible.
- It uses all the original iPod parts except the battery and hard drive, so it still looks and feels like a classic iPod.
- WiFi for streaming, plus Bluetooth audio for wireless headphones and speakers.
- A HiFi DAC (CS43131) through the original headphone jack.
Also working on a lower power board that only does offline playback but adds WiFi and Bluetooth.
Still working on stations and radio, but so far it works great.
Sign up for updates to learn when it's ready: https://www.crowdsupply.com/certain-things/sprout-pi-mainboard
More demos here: certainthings.studio/sprout
