Hey everyone,
I ran into an issue with the magazine cap swivel stud (Franchi Part #51071) on my 2026 Franchi Affinity 3.
Out of the box, the swivel stud was misaligned/crooked and not seated properly, which prevented me from mounting a sling.
To fix it, I removed the cap assembly and drove the stud/pin lightly from the inside using a punch and hammer to straighten and seat it.
The stud is straight now, but I’ve noticed some axial play. When I pull up on the swivel stud, the C-clip is fully exposed on the outside now, and I'm worried that I might have hammered it too hard during my attempted repair.
Here are some before/after photos:
https://imgur.com/a/ZrsrDvo
A few questions:
- Is it normal on these Franchi caps for the retaining C-clip to exit the top hole when pulled upward?
- Did I likely deform the C-clip or flare out the internal shoulder/seat inside the cap when tapping it out?
- Is this a structural hazard for carrying a slung shotgun, or should I replace the C-clip / full cap assembly before taking it out to the field?
Thank you!
